UPOS-211 Series

UPOS-211K

15英寸4:3 紧凑时尚型POS一体机，内置Intel® N50/N97/Core™ i3-N305 处理器

  • 15英寸TFT LCD（LED背光），带有PCAP触摸屏
  • 内置一个英特尔®N50/N97/酷睿™i3-N305处理器
  • 可扩展的I/O接口与USB-C和双局域网连接
  • 支持Windows 10 IoT, Windows 11 IoT和Linux操作系统
  • 紧凑型底座与一个可折叠的双转轴支架
  • 无风扇的设计，无尘和无噪音的操作
  • 清晰的电缆管理，方便地访问硬盘驱动器和USB端口
  • 可选多元化外设和安装

认证：

技术资源链接：

产品型录 技术文件下载
  • 15英寸4:3 紧凑时尚型POS一体机，内置Intel® N50/N97/Core™ i3-N305 处理器

规格

Display
Size
  • 15" TFT LCD
    (1024 x 768)
  • 15" TFT LCD
    (1024 x 768)
  • 15" TFT LCD
    (1024 x 768)
  • 15" TFT LCD
    (1024 x 768)
  • 15" TFT LCD
    (1024 x 768)
Brightness
  • 300 cd/m²
  • 300 cd/m²
  • 300 cd/m²
  • 300 cd/m²
  • 300 cd/m²
Touch Screen
Type
  • Projected Capacitive Touch Panel (Pcap. Flat Glass)
  • Projected Capacitive Touch Panel (Pcap. Flat Glass)
  • Projected Capacitive Touch Panel (Pcap. Flat Glass)
  • Projected Capacitive Touch Panel (Pcap. Flat Glass)
  • Projected Capacitive Touch Panel (Pcap. Flat Glass)
Processor System
CPU
  • Intel® N97
  • Intel® Core™ i3-N305
  • Intel® N97
  • Intel® N97
  • Intel® Atom® N97
RAM
  • 8 GB DDR5-4800
  • 8 GB DDR5-4800
  • 8 GB DDR5-4800
  • 8 GB DDR5-4800
  • 8 GB DDR5-4800
Storage
  • 1 x 2.5" SATA HDD/SSD Connector, SATA3
  • 1 x 2.5" SATA HDD/SSD Connector, SATA3
  • 1 x 2.5" SATA HDD/SSD Connector, SATA3
  • 1 x 2.5" SATA HDD/SSD Connector, SATA3
  • 128GB SSD
OS
  • N/A
  • N/A
  • N/A
  • N/A
  • Win 11 GAC
I/O Interface
Serial Port
  • 2 x COM
  • 2 x COM
  • 2 x COM
  • 2 x COM
  • 2 x COM
USB Port
  • 3 x USB 2.0, 2 x USB 3.2, 3 x USB-C
  • 3 x USB 2.0, 2 x USB 3.2, 3 x USB-C
  • 3 x USB 2.0, 2 x USB 3.2, 3 x USB-C
  • 3 x USB 2.0, 2 x USB 3.2, 3 x USB-C
  • 3 x USB 2.0, 2 x USB 3.2, 3 x USB-C
Ethernet
  • 2 x 2.5G LAN
  • 2 x 2.5G LAN
  • 2 x 2.5G LAN
  • 2 x 2.5G LAN
  • 2 x 2.5G LAN
Cash Drawer
  • 1 x RJ11
  • 1 x RJ11
  • 1 x RJ11
  • 1 x RJ11
  • 1 x RJ11
Display Output
  • 1 x USB-C type for 2nd display
  • 1 x USB-C type for 2nd display
  • 1 x USB-C type for 2nd display
  • 1 x USB-C type for 2nd display
  • 1 x USB-C type for 2nd display
Audio
  • 1 x 2 W Speaker
  • 1 x 2 W Speaker
  • 1 x 2 W Speaker
  • 1 x 2 W Speaker
  • 1 x 2 W Speaker
Extendable Slot
  • 1 x M.2 2230 E-Key for Wi-Fi & BT combo
    1 x M.2 M-Key 2280 for SSD
  • 1 x M.2 2230 E-Key for Wi-Fi & BT combo
    1 x M.2 M-Key 2280 for SSD
  • 1 x M.2 2230 E-Key for Wi-Fi & BT combo
    1 x M.2 M-Key 2280 for SSD
  • 1 x M.2 2230 E-Key for Wi-Fi & BT combo
    1 x M.2 M-Key 2280 for SSD
  • 1 x M.2 2230 E-Key for Wi-Fi & BT combo
    1 x M.2 M-Key 2280 for SSD
Power Jack
  • 1 x DC 20 V (USB-C Connector)
  • 1 x DC 20 V (USB-C Connector)
  • 1 x DC 20 V (USB-C Connector)
  • 1 x DC 20 V (USB-C Connector)
  • 1 x DC 20 V (USB-C Connector)
Power Supply
Input Voltage
  • 65W power adapter
  • 65W power adapter
  • 65W power adapter
  • 65W power adapter
  • 65W power adapter
Environment
System Protection
  • IP65 front panel
  • IP65 front panel
  • IP65 front panel
  • IP65 front panel
  • IP65 front panel
Color
Color
  • Black
  • Black
  • Black
  • White
  • Black
Peripheral
Stand
  • Included
  • Included
  • N/A
  • Included
  • Included
