边缘智能网关——快速联网 轻松运维

ECU-150 V2

ECU-150 V2 includes two RS-232/485 isolated serial ports, two 10/100/1000 Ethernet ports, and a USB 3.0 port, ensuring seamless connectivity.

  • NXP i.MX8M Plus Quad-core Cortex A53 CPU up to 1.6GHz
  • LPDDR4 2/4GB up to 8GB, eMMC 16/32GB up to 128GB for system storage
  • 2x isolated serial ports, configurable for RS232/485
  • 2x 10/100/1000 Ethernet ports
  • 2x M.2 expansion available
  • Add-on modules available for CAN FD expansion
  • Slim, robust, and fanless
  • Supports SD cards and OTA firmware updates

认证：

技术资源链接：

产品型录 技术文件下载
  • ECU-150 V2 includes two RS-232/485 isolated serial ports, two 10/100/1000 Ethernet ports, and a USB 3.0 port, ensuring seamless connectivity.

特点和优势

Ruggedized and Compact Design

  • Compact and small size
  • Battery-powered RTC, Watchdog and optional FRAM
  • Wide operating temperature -40 ~ 70°C

Multi-Protocol Conversion

  • 200+PLC Drivers
  • IEC-61850 / IEC-104 / DNP3 / Modbus / MQTT / OPC UA / BACnet / SNMP

Security Ready

  • Secure Boot: Hardware-enforced Root-of-Trust
  • TPM2.0: Available for sensitive information encryption
  • IEC 62443-4-2: Compliance to Europe CRA (2027), with 3rd party verified compliance

Effortless Integration

  • Flexibly expandable with wireless, and CAN FD capabilities
  • Gateway-ready EdgeLink software bundled with RESTful API
  • Ready-to-use pre-built ubuntu image and BSP/SDK available
