基础模块

AMAX-5001

双通道电源输入与4路数字量输入模块（插片式）

  • 输入通道 : 4
  • 电平逻辑 : 湿接点 额定电压: 24VDC 逻辑 1: 10~30 VDC 与 -10~-30 VDC 逻辑 0: -3~3 VDC
  • 额定电压: 24VDC (± 20%)
  • 输入延时:从逻辑 0 到 1: 4ms 从逻辑 1 到 0: 4ms
  • 数字量滤波:3ms
  • 功耗:2W@24VDC
  • 看门狗定时器:System (1.6 seconds)
  • 工作/储存温度:-25 ~ 60°C (-14~140°F) / -40 ~ 85°C ( -40~185°F)

认证：

技术资源链接：

产品型录 Download 3D Model 技术文件下载
  • 双通道电源输入与4路数字量输入模块（插片式）

规格

General
Rated Voltage
  • 24 VDC (±20%)
Diagnosis Function
  • Over/under voltage for input 1&2
    Over current output on bus
Max Current on Bus
  • 2 A
Connectors
  • 1 x 4-pin plug-in screw terminal, 1 x 8-pin plug-in screw terminal
Protocol
  • EtherCAT
EtherCAT
Cycle Time
  • 100 μs
Hardware
Dual Power Input
  • Supported
Certification
  • CB, UL, CE, FCC Class A
LED Indicators
  • PWR, RUN / ERROR, Power Diagnosis LED
Power Consumption
  • 2 W@ 24 VDC
Digital Input
Input Voltage
  • Dry Contact
    Logic level 1: close to Iso.GND
    Logic level 0: open
    Wet Contact
    Rated voltage: 24 VDC
    Logic level 1: 10~30 VDC and -10~-30 VDC
    Logic level 0: -3~3 VDC
Channels
  • 4
Input Delay
  • From logic level 0 to 1:
    4 ms
    From logic level 1 to 0:
    4 ms
Digital Filter
  • 3 ms
Environment
Isolation Voltage
  • 2,000 VDC
Operating Temperature
  • -25~60 °C (-13~140 °F)
Relative Humidity
  • 95% RH (non-condensing)
Storage Temperature
  • -40~85 °C (-40~185 °F)
Storage Humidity
  • 95% RH (non-condensing)
Mechanical
Enclosure
  • PC
Mounting
  • DIN-rail
Weight (Net)
  • 84 g
Dimension (W x H x D)
  • 14.6 x 105.9 x 94.7 mm
