96PSD-A960W48-MS
DIN Rail Power Supply AC to DC 200-240V 960W 48V with PFC Function

  • 110m Slim design with 960 watts output
  • Input range 180 ~ 264 VAC
  • Built-in DC OK relay contact
  • Power boost with 130% peak load
  • High efficiency up to 94%

规格 下载规格表

  • Part Number
  • 相关讯息
Power Supply
  • Output Power
  • Input Power
  • Input Current (maximum)
  • Input Voltage
  • Input Frequency
  • Efficiency
  • Main Connector
  • Operating Temperature
  • Storage Temperature
  • Storage Humidity
  • MTBF (hours @ 25°C)
  • Dimensions (W x H x D)
  • Manufacturer
  • Safety
  • Power Derating
  • Output Rating
  • PFC Function
  • Air Cooling
  • LED
  • Mounting Rail

Power Supply

  • Output Power

    96PSD-A960W48-MS 960W
  • Input Power

    96PSD-A960W48-MS AC to DC
  • Input Current (maximum)

    96PSD-A960W48-MS 230V @ 6A
  • Input Voltage

    96PSD-A960W48-MS 180 ~ 264V
  • Input Frequency

    96PSD-A960W48-MS 47 ~ 63 Hz
  • Efficiency

    96PSD-A960W48-MS 94%
  • Main Connector

    96PSD-A960W48-MS Screw Terminal
  • Operating Temperature

    96PSD-A960W48-MS -30 ~ 70°C
  • Storage Temperature

    96PSD-A960W48-MS -40 ~ 85°C
  • Storage Humidity

    96PSD-A960W48-MS 10 ~ 95% RH
  • MTBF (hours @ 25°C)

    96PSD-A960W48-MS 69K
  • Dimensions (W x H x D)

    96PSD-A960W48-MS 110 x 125.2 x 150 mm
  • Manufacturer

    96PSD-A960W48-MS Mean Well
  • Safety

    96PSD-A960W48-MS CB/UL/TUV/CE/BSMI/UKCA
  • Power Derating

    96PSD-A960W48-MS Full load to 50°C, refer to Derating Curve
  • Output Rating

    96PSD-A960W48-MS 48V @ 20A
  • PFC Function

    96PSD-A960W48-MS Yes
  • Air Cooling

    96PSD-A960W48-MS Conventional
  • LED

    96PSD-A960W48-MS Green, DC OK
  • Mounting Rail

    96PSD-A960W48-MS TS35
